Overall Dimension |
|
|
Dimensions L*W*H (mm) |
7675*2490*3254 |
|
Wheelbase (mm) |
3300+1400 |
|
Overhang (mm) |
1475 (Front) / 1500 (Rear) |
|
Fuel Tank (L) |
300 |
|
Wheels |
9.0 x 22.5 |
|
Max. Gradeability (°) |
≤ 30 |
|
Front Suspension |
Leaf spring, 3-leaf |
|
Rear Suspension |
Leaf spring, 5-leaf |
|
Tyres (Front/Rear) |
295/80R22 .5 |
|
Transmission Model |
HW25712 XAL |
|
Gear Speed |
12 forward, 2 reverse |
|
Battery (V/Ah) |
2×12 / 180 |
|
Alternator (V) |
24 |
Engine |
|
|
Model |
MC11.43-61 |
|
Displacement (cc) |
10.518L |
|
Max. Rated Power (kw/rpm) |
316/ 1900 |
|
Max. Torque (Nm/rpm) |
2100/ 1000-1400 |
|
Speed Limit (km/h) |
60 |
|
Bore x Stroke (mm) |
120 x 155 |
Weight |
|
|
Unladen Weight (kg) |
9860 |
|
Gross Combination Weight (kg) |
28000 |
|
Front Axle Capacity (kg) |
7000 |
|
Rear Axle Capacity (kg) |
13000 x 2 |
