Overall Dimension |
|
|
Dimensions L*W*H (mm) |
9160*2540*3203 |
|
Wheelbase (mm) |
4100 + 1350 |
|
Overhang (mm) |
1475 (Front) / 900 (Rear) |
|
Minimum Turning Diameter (m) |
24 |
|
Approach / Depart Angle (°) |
14 / 43 |
|
Max. Gradeability (°) |
≤ 30 |
|
Fuel Tank (L) |
300 |
|
Front Suspension |
Leaf spring, 10 |
|
Rear Suspension |
Leaf spring, 12 |
|
Drive Layout |
Rear Wheel Drive, 6×4 |
|
Transmission Model |
HW25712 XAL |
|
Gear Speed |
12 forward, 2 reverse |
|
Wheels |
9.0 x 22.5 |
Engine |
|
|
Model |
MC11.43-61 |
|
Displacement (cc) |
10.518L |
|
Max. Rated Power (kw/rpm) |
316/ 1900 |
|
Max. Torque (Nm/rpm) |
2100/ 1000-1400 |
|
Speed Limit (km/h) |
60 |
Weight |
|
|
Unladen Weight (kg) |
11460 |
|
Gross Combination Weight (kg) |
28000 |
|
Front Axle Capacity (kg) |
9500 |
|
Rear Axle Capacity (kg) |
16000 x 2 |
