Why SINOTRUK
SINOTRUK was listed on the main board of HKSE in 2007. Its parent company, China National Heavy Duty Truck Group Co. Ltd, is China’s first heavy-duty truck manufacturer. They became China’s first company to introduce foreign heavy-duty truck manufacturing technology. They also won the “National Award for Science and Technology Progress”, “Top 10 Outstanding Innovative Enterprise in China”, and “China Automobile Industry Science and Technology Progress” awards. SINOTRUK R&D Center is one of China’s first national-level corporate technology centers.
Overall Dimension |
|
|
Dimensions L*W*H (mm) |
6800*2500*3480 |
|
Wheelbase (mm) |
3200+1350 |
|
Overhang (mm) |
1475 (Front) / 725 (Rear) |
|
Fuel Tank (L) |
370 |
|
Wheels |
9.0 x 22.5 |
|
Front Suspension |
Leaf spring, 9-leaf |
|
Rear Suspension |
Leaf spring, 12-leaf |
|
Tyres (Front/Rear) |
385/65R22.5 315/80R22.5 |
|
Transmission Type |
HW25712XA (AMT) |
|
Gear Speed |
12 forward, 2 reverse |
|
Battery (V/Ah) |
2×12 / 180 |
|
Alternator (V) |
24 |
Engine |
|
|
Model |
MC13.54-61 |
|
Displacement (cc) |
12419 |
|
Max. Rated Power (kw/rpm) |
397/1800 |
|
Max. Torque (Nm/rpm) |
2500/1000-1400 |
|
Speed Limit (km/h) |
60 |
|
Bore x Stroke (mm) |
120 x 166 |
Weight |
|
|
Unladen Weight (kg) |
9000 |
|
Gross Combination Weight (kg) |
150000 |
|
Front Axle Capacity (kg) |
9500 |
|
Rear Axle Capacity (kg) |
26000 |
