Overall Dimension |
|
|
Dimensions L*W*H (mm) |
12000*2519*3279 |
|
Wheelbase (mm) |
1950+3600+1350 |
|
Overhang (mm) |
1475 (Front) / 3625 (Rear) |
|
Fuel Tank (L) |
400 |
|
Max. Gradeability (°) |
≤ 30 |
|
Front Suspension |
Leaf spring, 11/11-leaf |
|
Rear Suspension |
Leaf spring, 12-leaf |
|
Tyres (Front/Rear) |
315/80R22.5 |
|
Transmission Model |
HW25712 XAL |
|
Gear Speed |
12 forward, 2 reverse |
|
Cabin |
G7-F |
|
Cab Turning Radius (mm) |
2770 |
|
Battery (V/Ah) |
2×12 / 240 |
|
Alternator (V) |
24 |
Engine |
|
|
Model |
MC11.46-61 |
|
Displacement (cc) |
10.518L |
|
Max. Rated Power (kw/rpm) |
341/ 1900 |
|
Max. Torque (Nm/rpm) |
2200/ 1000-1400 |
|
Speed Limit (km/h) |
60 |
Weight |
|
|
Unladen Weight (kg) |
15200 |
|
Gross Combination Weight (kg) |
34000 |
|
Front Axle Capacity (kg) |
9500 x 2 |
|
Rear Axle Capacity (kg) |
16000 x 2 |
